FLANGED PLASTIC ENCLOSURE - TWF series


TWF Series -PDF

CATEGORY:Wall mount plastic enclosure, Flanged enclsoure, Plastic enclosure with flanged lid, Project box, Network enclosure

FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series
FLANGED PLASTIC ENCLOSURE - TWF series1
FLANGED PLASTIC ENCLOSURE - TWF series2
FLANGED PLASTIC ENCLOSURE - TWF series3
FLANGED PLASTIC ENCLOSURE - TWF series4
FLANGED PLASTIC ENCLOSURE - TWF series5
FLANGED PLASTIC ENCLOSURE - TWF series6
FLANGED PLASTIC ENCLOSURE - TWF series7
FLANGED PLASTIC ENCLOSURE - TWF series8
FLANGED PLASTIC ENCLOSURE - TWF series9
FLANGED PLASTIC ENCLOSURE - TWF series10
FLANGED PLASTIC ENCLOSURE - TWF series11
FLANGED PLASTIC ENCLOSURE - TWF series12
FLANGED PLASTIC ENCLOSURE - TWF series13
FLANGED PLASTIC ENCLOSURE - TWF series14
FLANGED PLASTIC ENCLOSURE - TWF series15
FLANGED PLASTIC ENCLOSURE - TWF series16
FLANGED PLASTIC ENCLOSURE - TWF series17
FLANGED PLASTIC ENCLOSURE - TWF series18

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Internal dimensions Color Weight (g) PDF DXF DWG STP
W H D w h d
TWF4-2-5D 35.4 22 50 27.2 13.2 32.4 Dark gray 19.7 PDF DXF DWG
TWF4-2-5W 35.4 22 50 27.2 13.2 32.4 Off-White 19.7 PDF DXF DWG
TWF5-2-5D 50.4 17 50 42.7 8 31.9 Dark gray 21.5 PDF DXF DWG
TWF5-2-5W 50.4 17 50 42.7 8 31.9 Off-White 21.5 PDF DXF DWG
TWF5-3-5D 50.4 27 50 42.7 18 31.9 Dark gray 29 PDF DXF DWG
TWF5-3-5W 50.4 27 50 42.7 18 31.9 Off-White 29 PDF DXF DWG
TWF5-2-7D 50.4 17 70 43.1 8 52.9 Dark gray 26.5 PDF DXF DWG
TWF5-2-7W 50.4 17 70 43.1 8 52.9 Off-White 26.5 PDF DXF DWG
TWF5-3-7D 50.4 29.5 70 43.1 20.5 52.9 Dark gray 36 PDF DXF DWG
TWF5-3-7W 50.4 29.5 70 43.1 20.5 52.9 Off-White 36 PDF DXF DWG
TWF5-4-7D 50.4 42 70 42.5 33 52.9 Dark gray 43 PDF DXF DWG
TWF5-4-7W 50.4 42 70 42.5 33 52.9 Off-White 43 PDF DXF DWG
TWF5-3-9D 45.6 27.5 90 37.2 17.5 70.4 Dark gray 43.5 PDF DXF DWG
TWF5-3-9W 45.6 27.5 90 37.2 17.5 70.4 Off-White 43.5 PDF DXF DWG
TWF7-2-11D 70.6 20.5 105 61.4 10.5 83 Dark gray 66.5 PDF DXF DWG
TWF7-2-11W 70.6 20.5 105 61.4 10.5 83 Off-White 66.5 PDF DXF DWG
TWF7-4-11D 70.6 35.5 105 61.4 25.5 83 Dark gray 87 PDF DXF DWG
TWF7-4-11W 70.6 35.5 105 61.4 25.5 83 Off-White 87 PDF DXF DWG
TWF7-5-11D 70.6 50.5 105 61.1 40.5 83 Dark gray 82 PDF DXF DWG
TWF7-5-11W 70.6 50.5 105 61.1 40.5 83 Off-White 82 PDF DXF DWG
TWF7-3-13D 65.5 25.5 130 57.7 14.2 105 Dark gray 96 PDF DXF DWG
TWF7-3-13W 65.5 25.5 130 57.7 14.2 105 Off-White 96.5 PDF DXF DWG
TWF7-5-13D 65.5 50 130 55.9 38.7 105 Dark gray 114 PDF DXF DWG
TWF7-5-13W 65.5 50 130 55.9 38.7 105 Off-White 114 PDF DXF DWG
TWF8-2-8D 80.6 23.5 80 71.5 13.5 59 Dark gray 62 PDF DXF DWG
TWF8-2-8W 80.6 23.5 80 71.5 13.5 59 Off-White 62 PDF DXF DWG
TWF8-4-8D 80.6 43.5 80 71.5 33.5 59 Dark gray 82 PDF DXF DWG
TWF8-4-8W 80.6 43.5 80 71.5 33.5 59 Off-White 82 PDF DXF DWG
TWF9-4-17D 86 35 170 76.5 23.7 143 Dark gray 150 PDF DXF DWG
TWF9-4-17W 86 35 170 76.5 23.7 143 Off-White 150 PDF DXF DWG
TWF9-6-17D 86 60 170 75.7 48.7 143 Dark gray 184 PDF DXF DWG
TWF9-6-17W 86 60 170 75.7 48.7 143 Off-White 184 PDF DXF DWG
TWF11-5-22D 110.3 45 220 100.8 33.7 191 Dark gray 250 PDF DXF DWG
TWF11-5-22W 110.3 45 220 100.8 33.7 191 Off-White 250 PDF DXF DWG
TWF11-8-22D 110.3 75 220 99.3 63.7 191 Dark gray 303 PDF DXF DWG
TWF11-8-22W 110.3 75 220 99.3 63.7 191 Off-White 303 PDF DXF DWG
TWF13-3-13D 125.6 25 125 114.5 13.7 100 Dark gray 155 PDF DXF DWG
TWF13-3-13W 125.6 25 125 114.5 13.7 100 Off-White 155 PDF DXF DWG
TWF13-5-13D 125.6 45 125 114.5 33.7 100 Dark gray 199 PDF DXF DWG
TWF13-5-13W 125.6 45 125 114.5 33.7 100 Off-White 199 PDF DXF DWG
TWF13-3-18D 125.6 25 175 114.5 13.7 148 Dark gray 189 PDF DXF DWG
TWF13-3-18W 125.6 25 175 114.5 13.7 148 Off-White 189 PDF DXF DWG
TWF13-5-18D 125.6 45 175 114.5 33.7 148 Dark gray 242 PDF DXF DWG
TWF13-5-18W 125.6 45 175 114.5 33.7 148 Off-White 242 PDF DXF DWG
TWF13-7-18D 125.6 65 175 114.2 53.7 148 Dark gray 281 PDF DXF DWG
TWF13-7-18W 125.6 65 175 114.2 53.7 148 Off-White 281 PDF DXF DWG
