WALL MOUNTING ENCLOSURES・FLANGED PLASTIC ENCLOSURES

WALL MOUNTING ENCLOSURES・FLANGED PLASTIC ENCLOSURES -PDF

CATEGORY: WALL MOUNTING ENCLOSURES・FLANGED PLASTIC ENCLOSURES・PLASIC ENCLOSURE WITH FLANGED LID

Specially designed for wall mounting use.
Flanged enclosures, Pole mount enclosures, DIN rail mount boxes are available.
Wall mounting brackets, pole mounting brackets, DIN rail mounting brackets are also available.
Suitable for WiFi access points, IOT sensors, controllers, data loggers, etc.

IP67 NETWORK PLASTIC BOX - WP series
  • IP67 NETWORK PLASTIC BOX - WP series
  • IP67 waterproof plastic enclosure. (NEMA 6P rating enclosure)
  • Easy pole mounting with optional mounting bracket.
  • Suiteble for wireless instruments, LoRa WAN, and access points.
  • 24 different selectable sizes are available.
  • NEW SIZE
DETAILS
FLANGED NETWORK PLASTIC BOX - PFF series
  • FLANGED NETWORK PLASTIC BOX - PFF series
  • Flat designed plastic enclosure with wall mounting flange.
  • Suitable for Wi-Fi access point, IOT gateway, data logger.
  • Plastic material : Flame-resistant ABS UL94V-0
  • 30 different sizes available for selection.
  • NEW SIZE
DETAILS
FLANGED PLASTIC ENCLOSURE - TWF series
  • FLANGED PLASTIC ENCLOSURE - TWF series
  • Multi-purpose flanged enclosure for wall-mount use.
  • Made of flame resistant ABS (UL94V-0).
  • For wireless network devices, controller, datalogger.
  • 23 different sizes in 2 colors.
    DETAILS
    NETWORK PLASTIC BOX - PF series
    • NETWORK PLASTIC BOX - PF series
    • Flat designed plastic box with detachable panels.
    • The most popular electronics plastic enclosure in Japan.
    • Made of flame-resistant ABS UL94V-0.
    • 36 different sizes in off-white and dark gray colors.
    • NEW SIZE
    DETAILS
    EMC SHIELDED PLASTIC BOX - PFE series
    • EMC SHIELDED PLASTIC BOX - PFE series
    • EMC shielded version of the PF series network plastic box.
    • The inside is coated with conductive paint.
    • Suitable for Wi-Fi access point, measuring equipment.
    • 4 different sizes are available.
      DETAILS
      NETWORK PLASTIC CASE - SU series
      • NETWORK PLASTIC CASE - SU series
      • Rounded shape design plastic enclosure.
      • Suitable for wall-mount communication device usage.
      • Snap on / off cover. No screws are required
      • 2 different sizes in white and light gray colors.
        DETAILS
        PLASTI BOX with HIGED COVER - OP series
        • PLASTI BOX with HIGED COVER - OP series
        • Plastic case with hinged cover.
        • General purpose case for wall-mount, desk-top.
        • 3 different sizes in light gray and black are available.
          DETAILS
          IP67 POLYCARBONATE ENCLOSURE - SPCP series
          • IP67 POLYCARBONATE ENCLOSURE - SPCP series
          • Waterproof polycarbonate enclosure for severe environment.
          • Protection class : IP67 (equivalent to NEMA6 rating)
          • For controller, network devices, outdoor measuring instrument.
          • 28 different sizes with 2 different cover types.
            DETAILS
            IP67 POLYCARBONATE BOX with KNOCKOUTS - SPCM series
            • IP67 POLYCARBONATE BOX with KNOCKOUTS - SPCM series
            • Waterproof polycarbonate junction box with knockouts.
            • Protection class : IP67 (equivalent to NEMA6 rating)
            • For junction box, control box, and wireless network devices.
            • 21 different sizes with 2 different cover types.
              DETAILS
              IP65 LATCH-HINGED ABS PLASTIC BOX - BCAP series
              • IP65 LATCH-HINGED ABS PLASTIC BOX - BCAP series
              • IP65 waterproof latch/hinged plastic enclosure.
              • ABS plastic - Low cost type.
              • White gray cover and Transparent cover are available.
              • 50 different sizes are available.
                DETAILS
                IP65 POLYCARBONATE BOX with KEY LOCK - BCPK series
                • IP65 POLYCARBONATE BOX with KEY LOCK - BCPK series
                • IP65 hinged polycabonate enclosure with key lock.
                • Made of UL94V-0 and high impact polycarbonate.
                • Operating Temperature -20℃~+75℃
                • 50 different sizes available.
                  DETAILS
                  IP67 FLANGED ALUMINUM ENCLOSURE - AW series
                  • IP67 FLANGED ALUMINUM ENCLOSURE - AW series
                  • IP67 and heat dissipation flanged aluminum enclosure.
                  • Tough and robust construction.
                  • Standard and EMC shielded models available.
                  • 34 different sizes in 4 different color combinations.
                    DETAILS
                    IP65 WALL MOUNT STAINLESS STEEL BOX - SLB series
                    • IP65 WALL MOUNT STAINLESS STEEL BOX - SLB series
                    • IP65 stainless steel enclosure with screw fixing cover.
                    • Equipped with wall mounting bracket.
                    • SUS304 stainless steel for weather and corrosion resistance.
                    • 9 different sizes are available.
                      DETAILS
                      IP65 WALLMOUNT HINGED STAINLESS STEEL BOX - SLM series
                      • IP65 WALLMOUNT HINGED STAINLESS STEEL BOX - SLM series
                      • IP65 hinged stainless steel enclosure with key lock latch.
                      • Equipped with wall mounting brackets.
                      • SUS304 stainless steel for weather and corrosion resistance.
                      • 9 different sizes are available.
                        DETAILS
                        IP65 FLANGED ENCLOSURE - EXWF series
                        • IP65 FLANGED ENCLOSURE - EXWF series
                        • Low cost type waterproof wallmount aluminium enclosure.
                        • Flanged end panels make it easy for wall mounting.
                        • Protection class : IP65 / IP54 (Depends on size)
                        • 67 different sizes in 6 color combinations.
                        • NEW PRODUCT
                        DETAILS
                        FLANGED EXTRUDED ALUMINUM ENCLOSURE - EXPF series
                        • FLANGED EXTRUDED ALUMINUM ENCLOSURE - EXPF series
                        • Wall mount extruded aluminum enclosure.
                        • Equipped with flanged frame for easy wall mounting.
                        • For Network devices, Controllers, Data loggers.
                        • 67 different sizes, 6 color combinations.
                        • NEW PRODUCT
                        DETAILS
                        FLANGED EMC SHIELD ENCLOSURE - EXEF series
                        • FLANGED EMC SHIELD ENCLOSURE - EXEF series
                        • EMC/EMI shielded aluminium enclosures with flanged frame.
                        • Equipped with flanged frame for easy wall mounting.
                        • For IOT network devices, Measuring instrument, Controllers.
                        • 67 different sizes in 3 color combinations.
                        • NEW PRODUCT
                        DETAILS
                        FLANGED NETWORK ALUMINIUM ENCLOSURE - MXF series
                        • FLANGED NETWORK ALUMINIUM ENCLOSURE - MXF series
                        • Flanged network enclosure with round edge design.
                        • Made of ABS plastic flanged panel and extruded aluminum.
                        • For IOT sensor, wireless device, access point and controller.
                        • 12 different sizes and 8 different color combinations.
                        • NEW PRODUCT
                        DETAILS
                        WALL MOUNT Raspberry Pi ACRYLIC CASE - RPA-4B-1F
                        • WALL MOUNT Raspberry Pi ACRYLIC CASE - RPA-4B-1F
                        • Wallmount transparent acrylic Raspberry Pi case.
                        • Exclusively for use with Raspberry Pi 4 model B.
                        • Wall mount flange is VESA100 size.
                        • Can be attached to the back of PC monitors.
                        • NEW PRODUCT
                        DETAILS
                        VESA MOUNT Raspberry Pi CASE -  RPI-F series
                        • VESA MOUNT Raspberry Pi CASE - RPI-F series
                        • VESA mount Raspberry Pi aluminum case.
                        • RPI-4B-1F : For Raspberry Pi 4 Model B
                        • RPI-1F : For Raspberry Pi 2B / 3B / 3B+
                        • NEW PRODUCT
                        DETAILS
                        Raspberry Pi DIN RAIL BOX - RPD-4 series
                        • Raspberry Pi DIN RAIL BOX - RPD-4 series
                        • DIN rail mountable Raspberry Pi 4B enclosure.
                        • Exclusively for use with 35mm DIN rail.
                        • Flat shape type and transparent window type are available.
                        • NEW PRODUCT
                        DETAILS
                        DIN RAIL MOUNTING BASE - DRA series
                        • DIN RAIL MOUNTING BASE - DRA series
                        • DIN rail mounting base for 35mm DIN rail.
                        • Simple installation and removal via the pull lever.
                        • Max load : 5kg.
                        • 3 different sizes available.
                          DETAILS
                          LOW COST DIN-RAIL MOUNTING PLATE - DRT series
                          • LOW COST DIN-RAIL MOUNTING PLATE - DRT series
                          • Low cost DIN rail mounting plate for 35mm DIN rail.
                          • Simple installation and removal by tilting action.
                          • Max load : 1 kg
                          • Material : PBT UL94V-0
                            DETAILS
                            DIN RAIL MOUNTING BRACKET - CKD series
                            • DIN RAIL MOUNTING BRACKET - CKD series
                            • Mounting bracket for 35mm DIN rail.
                            • Max load : 3kg, Can be easily detached.
                            • Material : Polyamide
                            • 3 sizes are available.
                              DETAILS
                              WALL SUSPENSION BRACKET - WM series
                              • WALL SUSPENSION BRACKET - WM series
                              • Quick release type wall mounting bracket.
                              • Easy attachment and removal.
                              • Large and small brackets in off-white and dark gray colors.
                                DETAILS
                                POLE MOUNTING BRACKET - WPMB-M4-3
                                • POLE MOUNTING BRACKET - WPMB-M4-3
                                • Bracket to mount enclosures onto a pole.
                                • Made from weather resistant ASA material.
                                • Suitable for both for vertical and horizontal mounting.
                                • Hole milling is required for bracket installation.
                                • NEW PRODUCT
                                DETAILS
                                POLE MOUNTING BELT- PKB series
                                • POLE MOUNTING BELT- PKB series
                                • Universal pole mounting belt for outdoor enclosures.
                                • Stainless steel type and plastic type are available.
                                • Use SSK mounting bracket for installation onto a pole.
                                  DETAILS
                                  POLE MOUNTING BRACKET - SSK series
                                  • POLE MOUNTING BRACKET - SSK series
                                  • Stainless steel pole mount bracket.
                                  • Can be attached to TAKACHI plastic boxes without hole milling.
                                  • Use optional mounting belt to install onto a pole. (PKB series)
                                  • 16 different sizes for variety of enclosures to mount.
                                    DETAILS
                                    WATERPROOF SEALING WASHER SZ series
                                    • WATERPROOF SEALING WASHER SZ series
                                    • Waterproof washer for screwing onto waterproof boxes.
                                    • Oil resistant NBR sealing material on N models.
                                    • Superior water resistant silicone sealing material on S models.
                                    • 8 sizes in M3, M4, M5, M6, M8, M10, M12, and M16.
                                      DETAILS
                                      PCB MOUNTING SCREW - EM series
                                      • PCB MOUNTING SCREW - EM series
                                      • Self tapping screws for PCB bosses on the plastic cases.
                                      • Use them to install your PCB onto bosses on the plastic cases.
                                      • Available for M1.6, M2, M2.3, M2.6, and M3 screws.
                                        DETAILS
                                        TORX DRIVE SCREW for PLASTIC CASES - MR series
                                        • TORX DRIVE SCREW for PLASTIC CASES - MR series
                                        • Hexalobular (TORX) screws for plastic enclosures.
                                        • Fit to CS・CSS・LC・PF・PFF・TW・TWN・TWF series.
                                        • Recommended to be used for tamper resistance.
                                          DETAILS
                                          TAPPING STANDOFF - TPS series
                                          • TAPPING STANDOFF - TPS series
                                          • Female standoff with tapping screw.
                                          • Easy installation onto existing enclosure boss mount.
                                          • M2.3・M2.6・M3 thread and 4~12mm length are available.
                                            DETAILS
