IP65 hinged stainless steel enclosure with key lock latch.
Made of SUS304 stainless steel for superior weather and corrosion resistance.
Conductive box for EMC shielding.

Surface finish : Polished finish.
Protection class : IP65
Operating temperature : -40℃ ~ +90℃

9 different sizes are available.
3D View  Exploded view 

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Internal dimensions Weight (g) PDF DXF DWG STP
W H D w h d
SSM121508 120 80.5 150 84 68.1 130.5 1000 PDF DXF DWG
SSM151508 150 80.5 150 114 68.1 130.5 1200 PDF DXF DWG
SSM152206 150 60.5 220 114 51.6 200.5 1400 PDF DXF DWG
SSM152210 150 100.5 220 114 88.1 200.5 1700 PDF DXF DWG
SSM202010 200 100.5 200 164 88.1 180.5 1900 PDF DXF DWG
SSM202806 200 60.5 280 164 51.6 260.5 2000 PDF DXF DWG
SSM202812 200 120.5 280 164 108.1 260.5 2600 PDF DXF DWG
SSM223312 220 120.5 330 184 108.1 310.5 3000 PDF DXF DWG
SSM304015 300 150.5 400 264 138.1 380.5 4800 PDF DXF DWG
Mounting plate (Option) PDF DXF DWG
SSC1215 PDF DXF DWG
SSC1515 PDF DXF DWG
SSC1522 PDF DXF DWG
SSC1522 PDF DXF DWG
SSC2020 PDF DXF DWG
SSC2028 PDF DXF DWG
SSC2028 PDF DXF DWG
SSC2233 PDF DXF DWG
SSC3040 PDF DXF DWG
