HEATSINK ALUMINUM CASE - HEN series


HEN Series -PDF

CATEGORY:Heatsink enclosure, Heat sink case, Heat dissipating enclosure, Cooling case, Headphone amplifier case

HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series
HEATSINK ALUMINUM CASE - HEN series1
HEATSINK ALUMINUM CASE - HEN series2
HEATSINK ALUMINUM CASE - HEN series3
HEATSINK ALUMINUM CASE - HEN series4
HEATSINK ALUMINUM CASE - HEN series5
HEATSINK ALUMINUM CASE - HEN series6
HEATSINK ALUMINUM CASE - HEN series7
HEATSINK ALUMINUM CASE - HEN series8

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Internal dimensions Color Weight (g) PDF DXF DWG
W H D w h d
HEN110206S 111.2 21.4 60 92.4 16.4 56 Silver 143 PDF DXF DWG
HEN110206B 111.2 21.4 60 92.4 16.4 56 Black 143 PDF DXF DWG
HEN110212S 111.2 21.4 120 92.4 16.4 116 Silver 258 PDF DXF DWG
HEN110212B 111.2 21.4 120 92.4 16.4 116 Black 258 PDF DXF DWG
HEN110220S 111.2 21.4 200 92.4 16.4 196 Silver 411 PDF DXF DWG
HEN110220B 111.2 21.4 200 92.4 16.4 196 Black 411 PDF DXF DWG
HEN110306S 111.2 32.5 60 92.4 27.5 56 Silver 179 PDF DXF DWG
HEN110306B 111.2 32.5 60 92.4 27.5 56 Black 179 PDF DXF DWG
HEN110312S 111.2 32.5 120 92.4 27.5 116 Silver 311 PDF DXF DWG
HEN110312B 111.2 32.5 120 92.4 27.5 116 Black 311 PDF DXF DWG
HEN110320S 111.2 32.5 200 92.4 27.5 196 Silver 488 PDF DXF DWG
HEN110320B 111.2 32.5 200 92.4 27.5 196 Black 488 PDF DXF DWG
HEN110406S 111.2 43.6 60 92.4 38.6 56 Silver 215 PDF DXF DWG
HEN110406B 111.2 43.6 60 92.4 38.6 56 Black 215 PDF DXF DWG
HEN110412S 111.2 43.6 120 92.4 38.6 116 Silver 365 PDF DXF DWG
HEN110412B 111.2 43.6 120 92.4 38.6 116 Black 365 PDF DXF DWG
HEN110420S 111.2 43.6 200 92.4 38.6 196 Silver 565 PDF DXF DWG
HEN110420B 111.2 43.6 200 92.4 38.6 196 Black 565 PDF DXF DWG
HEN110506S 111.2 54.7 60 92.4 49.7 56 Silver 250 PDF DXF DWG
HEN110506B 111.2 54.7 60 92.4 49.7 56 Black 250 PDF DXF DWG
HEN110512S 111.2 54.7 120 92.4 49.7 116 Silver 417 PDF DXF DWG
HEN110512B 111.2 54.7 120 92.4 49.7 116 Black 417 PDF DXF DWG
HEN110520S 111.2 54.7 200 92.4 49.7 196 Silver 640 PDF DXF DWG
HEN110520B 111.2 54.7 200 92.4 49.7 196 Black 640 PDF DXF DWG
HEN110606S 111.2 65.8 60 92.4 60.8 56 Silver 286 PDF DXF DWG
HEN110606B 111.2 65.8 60 92.4 60.8 56 Black 286 PDF DXF DWG
HEN110612S 111.2 65.8 120 92.4 60.8 116 Silver 471 PDF DXF DWG
HEN110612B 111.2 65.8 120 92.4 60.8 116 Black 471 PDF DXF DWG
HEN110620S 111.2 65.8 200 92.4 60.8 196 Silver 717 PDF DXF DWG
HEN110620B 111.2 65.8 200 92.4 60.8 196 Black 717 PDF DXF DWG
HEN110806S 111.2 88 60 92.4 83 56 Silver 358 PDF DXF DWG
HEN110806B 111.2 88 60 92.4 83 56 Black 358 PDF DXF DWG
HEN110812S 111.2 88 120 92.4 83 116 Silver 577 PDF DXF DWG
HEN110812B 111.2 88 120 92.4 83 116 Black 577 PDF DXF DWG
HEN110820S 111.2 88 200 92.4 83 196 Silver 869 PDF DXF DWG
HEN110820B 111.2 88 200 92.4 83 196 Black 869 PDF DXF DWG
