HEATSINK ALUMINUM CASE - HIT series


HIT Series -PDF

CATEGORY:Heatsink enclosure, Heat sink case, Cooling case, Heat dissipating enclosure, Amplifier case

HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series
HEATSINK ALUMINUM CASE - HIT series1
HEATSINK ALUMINUM CASE - HIT series2
HEATSINK ALUMINUM CASE - HIT series3
HEATSINK ALUMINUM CASE - HIT series4
HEATSINK ALUMINUM CASE - HIT series5
HEATSINK ALUMINUM CASE - HIT series6
HEATSINK ALUMINUM CASE - HIT series7
HEATSINK ALUMINUM CASE - HIT series8

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Internal dimensions Weight (g) Color PDF DXF DWG
W H D w h d
HIT9-2-13SS 89 20 130 72 13 122.8 183 Silver PDF DXF DWG
HIT9-2-13BB 89 20 130 72 13 122.8 183 Black PDF DXF DWG
HIT9-4-13SS 89 40 130 72 33 122.8 255 Silver PDF DXF DWG
HIT9-4-13BB 89 40 130 72 33 122.8 255 Black PDF DXF DWG
HIT13-3-13SS 130 30 130 113 23 122.8 289 Silver PDF DXF DWG
HIT13-3-13BB 130 30 130 113 23 122.8 289 Black PDF DXF DWG
HIT13-5-13SS 130 50 130 113 43 122.8 370 Silver PDF DXF DWG
HIT13-5-13BB 130 50 130 113 43 122.8 370 Black PDF DXF DWG
HIT18-4-13SS 180 40 130 163 33 122.8 414 Silver PDF DXF DWG
HIT18-4-13BB 180 40 130 163 33 122.8 414 Black PDF DXF DWG
HIT18-6-13SS 180 60 130 163 53 122.8 503 Silver PDF DXF DWG
HIT18-6-13BB 180 60 130 163 53 122.8 503 Black PDF DXF DWG
HIT13-3-18SS 128 30 180 103 23 172.8 411 Silver PDF DXF DWG
HIT13-3-18BB 128 30 180 103 23 172.8 411 Black PDF DXF DWG
HIT13-5-18SS 128 50 180 103 43 172.8 535 Silver PDF DXF DWG
HIT13-5-18BB 128 50 180 103 43 172.8 535 Black PDF DXF DWG
HIT17-4-18SS 174 40 180 149 33 172.8 578 Silver PDF DXF DWG
HIT17-4-18BB 174 40 180 149 33 172.8 578 Black PDF DXF DWG
HIT17-6-18SS 174 60 180 149 53 172.8 719 Silver PDF DXF DWG
HIT17-6-18BB 174 60 180 149 53 172.8 719 Black PDF DXF DWG
HIT23-5-18SS 228 50 180 203 43 172.8 772 Silver PDF DXF DWG
HIT23-5-18BB 228 50 180 203 43 172.8 772 Black PDF DXF DWG
HIT23-7-18SS 228 70 180 203 63 172.8 928 Silver PDF DXF DWG
HIT23-7-18BB 228 70 180 203 63 172.8 928 Black PDF DXF DWG
