ALUMINUM PROJECT BOX - T series


T Series -PDF

CATEGORY:Project box, Aluminum box, Sheet metal enclosure, Aluminum chassis, Control box, DIY project box

ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series
ALUMINUM PROJECT BOX - T series1
ALUMINUM PROJECT BOX - T series2
ALUMINUM PROJECT BOX - T series3
ALUMINUM PROJECT BOX - T series4
ALUMINUM PROJECT BOX - T series5
ALUMINUM PROJECT BOX - T series6
ALUMINUM PROJECT BOX - T series7
ALUMINUM PROJECT BOX - T series8
ALUMINUM PROJECT BOX - T series9

PRODUCT NO. / DIMENSIONS

Product No. External dimensions Internal dimensions Weight (g) PDF DXF DWG STP
W H D w h d
T 8-4-5 80 35 50 69 32 33 49.5 PDF DXF DWG
T 10-4-7 100 40 70 89 37 53 78 PDF DXF DWG
T 10-7-10 100 70 100 89 67 83 134.5 PDF DXF DWG
T 12-5-8 120 50 80 109 47 63 110 PDF DXF DWG
T 12-7-7 120 70 70 109 67 53 122.5 PDF DXF DWG
T 15-5-10 150 50 100 139 47 83 153 PDF DXF DWG
T 15-9-15 150 85 150 139 82 133 261 PDF DXF DWG
T 16-7-9 160 70 90 149 67 73 179 PDF DXF DWG
T 20-6-13 200 60 130 189 57 113 252.5 PDF DXF DWG
T 22-8-14 220 80 140 209 77 123 332.5 PDF DXF DWG
T 25-6-15 250 60 150 239 57 133 339 PDF DXF DWG
T 30-7-18 300 70 180 289 67 163 488.5 PDF DXF DWG
