POLE MOUNTING BRACKET for WP - WPMB series


WPMB Series -PDF

CATEGORY:Pole mounting bracket, Pole mount bracket

POLE MOUNTING BRACKET for WP - WPMB series
POLE MOUNTING BRACKET for WP - WPMB series
POLE MOUNTING BRACKET for WP - WPMB series1
POLE MOUNTING BRACKET for WP - WPMB series2
Pole mount bracket made from weather resistant ASA material.
Hole milling is not required when installing the mount bracket, thus allowing the enclosure to maintain its IP67 protection.
WPMB-M4-2 can be used both for vertical and horizontal installation.

Together with WPMB series, the PKB series mounting belt enables the unit to be mounted onto a pole.

PRODUCT NO. / DIMENSIONS

Product No. Suitable enclosures Color / Similar matching Weight (g) / 1pcs Pack of PDF DXF DWG STP
WPMB-M3D WP5-7-2 ・ 5-7-3 ・ 6-8-2 ・ 6-8-3 ・ 8-8-2 ・ 8-8-4 ・ 8-10-2 ・ 8-10-4 Dark gray / Munsell N3 1.5 2 pcs (Pair) PDF DXF DWG
WPMB-M3G WP5-7-2 ・ 5-7-3 ・ 6-8-2 ・ 6-8-3 ・ 8-8-2 ・ 8-8-4 ・ 8-10-2 ・ 8-10-4 White gray / Munsell Munsell N8.75 1.5 2 pcs (Pair) PDF DXF DWG
WPMB-M4D WP9-13-3 ・ 9-13-4 ・ 10-10-3 ・ 10-10-4 ・ 11-15-3 ・ 11-15-4 ・ 13-18-3 ・ 13-18-5 Dark gray / Munsell N3 5 2 pcs (Pair) PDF DXF DWG
WPMB-M4G WP9-13-3 ・ 9-13-4 ・ 10-10-3 ・ 10-10-4 ・ 11-15-3 ・ 11-15-4 ・ 13-18-3 ・ 13-18-5 White gray / Munsell Munsell N8.75 5 2 pcs (Pair) PDF DXF DWG
WPMB-M4-2D WP15-15-4 ・ 15-15-6 ・ 15-21-4 ・ 15-21-6 ・ 20-20-5 ・ 20-20-7 ・ 20-28-5 ・ 20-28-7 Dark gray / Munsell N3 24 1 pcs PDF DXF DWG
WPMB-M4-2G WP15-15-4 ・ 15-15-6 ・ 15-21-4 ・ 15-21-6 ・ 20-20-5 ・ 20-20-7 ・ 20-28-5 ・ 20-28-7 White gray / Munsell Munsell N8.75 24 1 pcs PDF DXF DWG
SAMPLE REQUEST FORM

This product series is available as a free sample.

OPTIONAL PARTS

1
POLE MOUNTING BELT- PKB series
DETAILS

SIMILAR PRODUCT

1
POLE MOUNTING BRACKET - WPMB-M4-3
DETAILS
